Ideal for long-term installations, post-driven chain link fence makes an excellent semi-permanent barrier that offers durable, reliable security at an affordable cost.
Chain Link Fabric Roll
Chain Link Fabric Roll 6‘x 50‘ - Shrinking Roll
Wire Diameter: 2.8 mm (0.11 Inch)
Chain Link Mesh Size: 57 mm x 57 mm (2.25 Inch)
Chain Link Mesh End: Knuckle-Knuckle
Weight/Roll: 53.30 KG (109 LB)
Non-Shrinking Diameter: 260mm (10 Inch)
Packaging: 20 Rolls/Wooden Boxes
Wooden Box Size (ft): 6.5(L) x 3.6(W) x 3.6(H)
How to Unwind?
It all begins with ideas for saving shipping costs, storage space, and easy for handling. The shirked chain link fabric roll makes all the difference.
Tension / Brace Bands
For Terminal Post: 2-3/8”
For Line Post: 1-7/8”
Top Rail Post: 1-1/4”
Loop / End Caps
Terminal Cap: 2-3/8”
Line Cap: 1-7/8”
Connecting Sleeves
For Terminal Post:
For Line Post:
For Top Rail Post:
Aluminum
6-1/2”; 9 Guage; 25/Bag
Galvanized Tie Wires
9-1/2”; 9 Guage; 25/Bag
